SAB Kabel

HV analog sensor cable 4 x 2 x AWG 28

item no. L3801-9192 / item no. L3801-9196

SAB BRÖCKSKES · D-VIERSEN · CSM GmbH · D-FILDERSTADT · L3801-9196 · HV-ANALOG

SAB BRÖCKSKES · D-VIERSEN · CSM GmbH · D-FILDERSTADT · L3801-9196 · HV-ANALOG

Application

High voltage analog sensor cable for operating temeraturs up to -40°C.

Construction

Operating temperature

fixed laying -40 °C to +150 °C (3000 h)

Min. bending radius

12 x cable diameter

Diameter

L3801-9192: approx. 7,1 mm

L3801-9196: approx. 7,2 mm

Voltage

max. 1000V

Marking

L3801-9192: SAB BRÖCKSKES · D-VIERSEN · CSM GmbH · D-FILDERSTADT · L3801-9192 · HV-ANALOG

L3801-9196: SAB BRÖCKSKES · D-VIERSEN · CSM GmbH · D-FILDERSTADT · L3801-9196 · HV-ANALOG
