General Information SABIX®

SABIX® - thermoplastic material on a polyolefine base

This material has several outstanding characteristics. As registered trademark of SAB Bröckskes GmbH & Co. KG, SABIX® combines progressive cable technology with highest security for the user. When used properly, there is no health risk associated with SABIX®. SABIX® products are completely recyclable and can be reused after decomposition.


Standard halogen-free cables offer a large degree of safety to humans, nature, buildings and machinery, but do have a large disadvantage - they are often too unflexible to compete with PVC in all applications. This is not the case with SABIX®. SABIX® possesses several technical advantages compared with PVC.



The outstanding characteristics of the C-material types depending on the modifications are:

  • oil resistance acc. to DIN VDE + EN
  • flexible at low temperatures up to -40°C
  • heat resistant up to +90°C
  • suitable for outdoor application, extremly flexible
  • very good capacitance values
  • increased abrasion resistance
  • fully recyclable
  • low smoke density acc. to DIN VDE, IEC, BS + EN
  • flame retardant and self-extinguishing acc. to DIN VDE, IEC + EN
  • halogen-free acc. to DIN VDE + IEC
  • UL/ CSA



Examples for applications

SABIX® - single conductors, wiring- and conductor cables:control cabinets, devices for communication technology, domestic appliances, generators, transformers and machine tools, railway technology,

SABIX® - control and connection cables:automation technology, automotive industry, mechanical engineering, railway engineering, conveyor technology, industrial plant construction, steel and iron industry, refrigeration and air conditioning, autowash roads, truck lifting platforms, supply line between frequency converter and servomotor, ...

SABIX® - data cables:communication technology, electronics for data processing systems, weighing devices, office machines, for increased transmission and crosstalk requirements, ... C Rail: Single wires, control and data cables for the internal wiring of rail vehicles according to DIN EN 45545-2, ...

SABIX® - BlueLine - cables for shipbuilding: BlueLine Data – Data cable, BlueLine Control – Control cable, BlueLine Power – Power cables, for flexible laying under deck, as well as the protected installation on deck of ships without permanent contact with oils and fuels.

SABIX® - Ultra - dauerflexibel mit höchstem Brandschutz:as a Festoon-cable for polar carriages in nuclear power plants, in railway technology, as a sensor cable on the vehicle chassis, as a drag chain insert with moderate mechanical loads, as a flexible control cable at entry ...
