USB 3.0 cable
with moulded type A and Micro-B male connector
Application
Connection cable PC – 3D camera
Outstanding features
Cable characteristics:
- mechanically very rugged
- PUR cable suitable for cable tracks
Additional information
Configuration example:
| item no. | length „L“ in cm |
|---|---|
| S0604-4004-00100 | 100 |
| S0604-4004-00200 | 200 |
| S0604-4004-00300 | 300 |
| S0604-4004-00500 | 500 |
Cable data
| Construction | 3x(2x30AWG)ST+2x24AWG |
|---|---|
| Insulation | SABIX® |
| Outer sheath | PUR |
| Outer diameter | approx. 6,1 mm |
| Min. bending radius | 10 x d |
| Peak operating voltage | max. 350 V |
| SAB marking | item number, order number, length |
Construction
3x(2x30AWG)ST+2x24AWG
Insulation
SABIX®
Outer sheath
PUR
Outer diameter
approx. 6,1 mm
Min. bending radius
10 x d
Peak operating voltage
max. 350 V
SAB marking
item number, order number, length
