SABmed T USB 3.0 Gen 1
Data cable
Application
Autoclavable USB Data Cable for interference-minimised display. Fields of application of the USB Data Cable include:
- Ultrasound
- Microscopy
- Endoscopy
- Monitoring
Upgraded for individual connectors possible.
Outstanding features
- non-sticky
- autoclavable
Typical Construction
| Conductor | finely-stranded, silver-plated copper |
|---|---|
| Insulation | FEP |
| Stranding | highest precise, homogenized stranding |
| Screen | highly-efficient tinned copper braid |
| Sheath material | biocompatible SABmed T |
Conductor
finely-stranded, silver-plated copper
Insulation
FEP
Stranding
highest precise, homogenized stranding
Screen
highly-efficient tinned copper braid
Sheath material
biocompatible SABmed T
Technical Data
| Voltage | up to 90 V |
|---|---|
| Temperature range | -40°C/+100°C |
| Testing voltage | selection test acc. to 2 MOP |
| Cleaning | standard whipe disinfection, ETO |
| Surface | „non-sticky“ |
| Harness | upgraded for individual connectors |
Voltage
up to 90 V
Temperature range
-40°C/+100°C
Testing voltage
selection test acc. to 2 MOP
Cleaning
standard whipe disinfection, ETO
Surface
„non-sticky“
Harness
upgraded for individual connectors
