>> Individual configuration for Ground Power supply cables for flexible applications <<
Your cable combination is not yet shown in our catalogue 400Hz and 28V DC? No problem! Using the following sample configuration, you can easily configure your individual combination of cable and the required connectors yourself. We will be happy to advise you. Just contact us directly.
Supply cable
| ☐ GP 400 QF | 4 x (50,0 + 4 x 1,0) - PUR |
| ☐ GP 400 QF | 4 x (70,0 + 4 x 1,0) - PUR |
| ☐ GP 400 QF | 4 x (50,0 + 4 x 1,0) - Special polymer |
| ☐ GP 400 QF | 4 x (70,0 + 4 x 1,0) - Special polymer |
| ☐ GP 400 SF | 7 x 25,0 + 6 x 3 x 1,0 |
| ☐ GP 400 SF | 7 x 35,0 + 6 x 3 x 1,0 |
Side 2
| ☐ wire end sleeves | _________________________ |
| ☐ pin terminals | _________________________ |
| ☐ ring cable lugs | _________________________ |
| ☐ plug | PPM 400P |
| ☐ plug | PPM 400S socket |
Further accessories
| ☐ with 90% Switch | ☐ PIN E | ☐ PIN F | ☐ PIN E+F |
| ☐ push buttons | ☐ red | ☐ green | ☐ black |
| ☐ LED | ☐ red | ☐ green | ☐ yellow |
| ☐ thermocouple | ☐ PT100 | ☐ PTC120 | ☐ PTC100 |
| ☐ with strain relief | _________________________ mm behind connector end | ||
PDF Download:
Enquiry form - Pre-assembled 400Hz cables for Ground Power supply cables for flexible applications
Inspection certificate 3.1
An acceptance test certificate 3.1 (DIN EN 10204) is issued as standard for all assembled 400 Hz and 28 V DC cables. It documents the quality and safety tests and serves as proof of traceability. Each product is also marked separately to ensure clear identification and traceability.
Core tests:
- Insulation resistance at 500 V DC / 1 s (≥ 1 MΩ)
- High-voltage test at bei 2000 V DC / 60 s
For further tests, please refer to the sample acceptance test certificate:
