8-fold IEPE triax multicore cable
with 8 x female connector ¼-28 UNF, 4-pole and 8 x (3 x BNC connector)
Application
Multicore cable for structured and proper installation and recording, e.g. on the test bench
Additional information
customised plug design possible
Connector
| side 1 | female connector ¼-28 UNF, 4-pole* *please indicate your sensor type! |
|---|---|
| side 2 | 8 x (3x BNC male connector) |
side 1
female connector ¼-28 UNF, 4-pole*
*please indicate your sensor type!
side 2
8 x (3x BNC male connector)
Cable data
| construction | 8 x (4 x AWG 34)C – IEPE triax |
|---|---|
| insulation | TPFK |
| inner sheath | PUR |
| outer sheath | PUR |
| sheath colour | dark blue |
| outer diameter | approx. 11,7 mm |
| operating voltage | max. 150 V |
| temperature range | -40°C / +90°C (+125°C 2500h) |
construction
8 x (4 x AWG 34)C – IEPE triax
insulation
TPFK
inner sheath
PUR
outer sheath
PUR
sheath colour
dark blue
outer diameter
approx. 11,7 mm
operating voltage
max. 150 V
temperature range
-40°C / +90°C (+125°C 2500h)
Configuration example
| item no. | Sheath material | length "L" [mm] | |
|---|---|---|---|
| S3055-1030-00500 | PUR | 5000 mm | Send inquiry |
item no.
Sheath material
length "L" [mm]
SAB identification: item number, batch number
