Breakout box with 8-fold IEPE triax multicore cable
with 8 x Lemo inputs, 9-pole, code G and 8 x Lemo connector, 9-pole, code G
Application
In multi-channel NVH measurements with triaxial accelerometers, cabling effort can quickly become complex. The IEPE triax breakout box with 8-way multicore cable enables a structured and compact connection of multiple sensor signals to measurement systems via a single cable.
Compared to conventional single-cable solutions, the integrated multicore design reduces wiring complexity and supports stable and reproducible signal transmission. Up to eight triaxial accelerometers can be connected via one cable, simplifying the cabling of test benches and measurement systems.
The cable combines mechanical robustness with flexible handling and is designed for demanding environments thanks to its PUR jacket. Multi-layer shielding ensures reliable signal quality even in complex measurement setups.
Typical applications include test benches, in-vehicle measurements and laboratory environments with high channel density.
Custom configurations are available in terms of connectors, cable lengths and specific application requirements.
Outstanding features
- mechanically robust
- flexible and easy to route
- reduced cabling effort in multi-channel NVH measurements
- connection of up to 8 triaxial accelerometers via one cable
- customizable for different measurement setups
Additional information
also possible with BNC male connector
Connector
| side 1 | 8 x Lemo device mounting socket, 9-pole, code G, with dust protection flap cover |
|---|---|
| side 2 | 8 x insulated BNC male connector |
8 x Lemo device mounting socket, 9-pole, code G, with dust protection flap cover
8 x insulated BNC male connector
Cable data
| construction | 8 x (4 x AWG 34)C – IEPE triax |
|---|---|
| insulation | TPFP |
| inner sheath | PUR |
| outer sheath | PUR |
| sheath colour | dark blue |
| outer diameter | approx. 11,7 mm |
| operating voltage | max. 150 V |
| temperature range | -40°C / +90°C (+125°C 2500h) |
8 x (4 x AWG 34)C – IEPE triax
TPFP
PUR
PUR
dark blue
approx. 11,7 mm
max. 150 V
-40°C / +90°C (+125°C 2500h)
Box data
| housing | aluminium, black powder-coated |
|---|---|
| seal | TPE, black |
| protection class (applies only to the housing, not to the mounting socket) | IP65 / NEMA 3 |
| weight (without connector & cable) | approx. 285 g |
| dimension (W x H x D) | approx. 200 x 57 x 32 mm, with wall bracket: approx. 200 x 76 x 34,8 mm |
aluminium, black powder-coated
TPE, black
IP65 / NEMA 3
approx. 285 g
approx. 200 x 57 x 32 mm, with wall bracket: approx. 200 x 76 x 34,8 mm
Configuration example
| item no. | Sheath material | length "L" [mm] | |
|---|---|---|---|
| S3075-4041-00500 | PUR | 5000 mm | Send inquiry |
SAB identification: item number, batch number
