Connection cable
with mini female connector M4,5, 4-pole and 3 x BNC male connector
Application
connection cable with waterproof sensor connector IP 68 for triaxial acceleration sensors on IEPE Basis
Additional information
Further service aspects:
Individual marking by shrinkable sleeve as for example material number or barcode
Connector
| side 1 | mini female connector M4,5, 4-pole* *please indicate your sensor type! |
|---|---|
| side 2 | 3 x BNC male connector |
mini female connector M4,5, 4-pole*
*please indicate your sensor type!
3 x BNC male connector
Cable data (TPFP)
| construction | 4 x AWG 34 |
|---|---|
| insulation | TPFP |
| outer sheath | TPFP |
| sheath colour | blue |
| outer diameter | approx. 2,1 mm |
| operating voltage | max. 150 V |
| temperature range | -55°C / +250°C |
| special characteristics | resistant to high temperatures |
4 x AWG 34
TPFP
TPFP
blue
approx. 2,1 mm
max. 150 V
-55°C / +250°C
resistant to high temperatures
Cable data (PUR)
| construction | 4 x AWG 34 |
|---|---|
| insulation | TPFP |
| outer sheath | PUR |
| sheath colour | black |
| outer diameter | approx. 2,5 mm |
| operating voltage | max. 150 V |
| temperature range | -40°C / +90°C (+125°C 2500h) |
| special characteristics | mechanically more robust |
4 x AWG 34
TPFP
PUR
black
approx. 2,5 mm
max. 150 V
-40°C / +90°C (+125°C 2500h)
mechanically more robust
Cable data (silicone)
| construction | 4 x AWG 30 |
|---|---|
| insulation | TPFP |
| outer sheath | silicone |
| sheath colour | turquoise |
| outer diameter | approx. 2,7 mm |
| operating voltage | max. 150 V |
| temperature range | -25°C / +180°C |
| special characteristics | highest flexibility |
4 x AWG 30
TPFP
silicone
turquoise
approx. 2,7 mm
max. 150 V
-25°C / +180°C
highest flexibility
Configuration examples
| item no. | Sheath material | length "L" [mm] | |
|---|---|---|---|
| S3031-2230-00300 | TPFP | 3000 mm | Send inquiry |
| S3032-2230-00300 | PUR | 3000 mm | Send inquiry |
| S3033-2230-00300 | silicone | 3000 mm | Send inquiry |
SAB identification: item number, batch number
