SAB Kabel

Control cables

19 x 1,0 mm² - (2 x 1,0 mm²) D + 3 x 3 x 1,0 mm² + 2 x 4 x 1,0 mm²

Construction

Conductor

bare copper strands acc. to IEC 60228

Insulation

TPE

Colour code

white cores with consecutive numbers acc. to EN 50334 + VDE 0293-334

and a green-yellow earth wire

Sheath material

PUR, TMPU

acc. to EN 50363-10-2 + VDE 0207-363-10-2

Sheath colour

black (RAL 9005)

Conductor

bare copper strands acc. to IEC 60228

Insulation

TPE

Colour code

white cores with consecutive numbers acc. to EN 50334 + VDE 0293-334

and a green-yellow earth wire

Sheath material

PUR, TMPU

acc. to EN 50363-10-2 + VDE 0207-363-10-2

Sheath colour

black (RAL 9005)

Technical data

Nominal voltage

max. 350 V

Testing voltage

core/core 1500 V

Temperature range

flexible application:

-40/+90 °C

Min. bending radius

recommended: 10 x d

Absence of harmful substances

acc. to RoHS directive of the European Union

Nominal voltage

max. 350 V

Testing voltage

core/core 1500 V

Temperature range

flexible application:

-40/+90 °C

Min. bending radius

recommended: 10 x d

Dimensions

item no. dimension outer-ø
0760-915119 x 0,7512,4 Send inquiry
0760-905619 x 1,0013,3 Send inquiry
item no.
dimension
outer-ø
0760-9151
19 x 0,75
12,4
0760-9056
19 x 1,00
13,3

Other dimensions and colours are possible on request.
