T713

Measuring insert

Gauge slide

Gauge slide

Construction

RTD

■ 1 x Pt 100 class B     ■ 2 x Pt 100 class B

■ 1 x Pt 100 class A     ■ 2 x Pt 100 class A

Connection type of inner wires

■ 2 - wire circuit

■ 3 - wire circuit

■ 4 - wire circuit

ø sheath / measuring tip / material no.

■ 3.0/3.0/1.4541

■ 4.5/4.5/1.4541

■ 6.0/6.0/1.4541

■ 6.0/4.0/1.4541

■ 6.0/8.0/1.4541

Measuring temperature range

■ -50 .... +400°C

■ -50 .... +600°C

■ -200 ...+600°C

Inset length

■ 145 mm     ■ 405 mm     ■ 825 mm

■ 205 mm     ■ 430 mm     ■ 1025 mm

■ 255 mm     ■ 435 mm     ■ 1275 mm

■ 275 mm     ■ 455 mm     ■ 1425 mm

■ 290 mm     ■ 525 mm     ■ 1625 mm

■ 315 mm     ■ 580 mm     ■ 1825 mm

■ 340 mm     ■ 655 mm     ■ 2025 mm

■ 375 mm     ■ 735 mm

■ other length - acc. to customer’s request
