T752

Measuring insert with connection socket

Gauge slide with connection socket

Gauge slide with connection socket

Construction

Thermocouple

- 1 x L

- 1 x J

- 1 x K

- 2 x L

- 2 x J

- 2 x K

Limit deviation / type of measuring tip

- class 1 / form A

- class 1 / form B

- class 2 / form A

- class 2 / form B

ø sheath / measuring tip

- 3.0

- 4.5

- 6.0

- 6.0/8.0

Sheath material

- 1.4541

- 2.4816

Inset length

- 145 mm

- 205 mm

- 255 mm

- 275 mm

- 290 mm

- 315 mm

- 340 mm

- 375 mm

- 405 mm

- 430 mm

- 435 mm

- 455 mm

- 525 mm

- 580 mm

- 655 mm

- 735 mm

- 825 mm

- 1025 mm

- 1275 mm

- 1425 mm

- 1625 mm

- 1825 mm

- 2025 mm

- other length - acc. to customer’s request

Thermocouple

- 1 x L

- 1 x J

- 1 x K

- 2 x L

- 2 x J

- 2 x K

Limit deviation / type of measuring tip

- class 1 / form A

- class 1 / form B

- class 2 / form A

- class 2 / form B

ø sheath / measuring tip

- 3.0

- 4.5

- 6.0

- 6.0/8.0

Sheath material

- 1.4541

- 2.4816

Inset length

- 145 mm

- 205 mm

- 255 mm

- 275 mm

- 290 mm

- 315 mm

- 340 mm

- 375 mm

- 405 mm

- 430 mm

- 435 mm

- 455 mm

- 525 mm

- 580 mm

- 655 mm

- 735 mm

- 825 mm

- 1025 mm

- 1275 mm

- 1425 mm

- 1625 mm

- 1825 mm

- 2025 mm

- other length - acc. to customer’s request
