SAB Kabel

CC 550 P

PUR control cable with numbered cores, halogen-free and oil resistant

Marking for CC 550 P 52790515: SAB BRÖCKSKES · D-VIERSEN · CC 550 P 5 x 1,5 mm² CE

Marking for CC 550 P 52790515: SAB BRÖCKSKES · D-VIERSEN · CC 550 P 5 x 1,5 mm² CE

Application

CC 550 P is a PUR control cable with numbered cores, it is halogen-free and oil resistant. Due to the PUR outer sheath the cable is recommended for machine and industrial plant construction, material handling techniques, car manufacturing industry, handling and automation technologies, iron, steel, and chemical industries.

Outstanding features

  • halogen-free
  • very good mechanical strength
  • abrasion resistant
  • notch resistant
  • good chemical resistance
  • oil resistant
  • flame retardant
  • sunlight resistant
  • weather resistant

Construction

Conductor

bare copper strands acc. to IEC 60228, VDE 0295, class 5

Insulation

SABIX®

Colour code

black cores with consecutive numbers acc. to EN 50334 + VDE 0293-334, green-yellow earth wire from 3 cores

Stranding

in layers

Sheath material

PUR, TMPU acc. to EN 50363-10-2 + VDE 0207-363-10-2

Sheath colour

black (RAL 9005)

Conductor

bare copper strands acc. to IEC 60228, VDE 0295, class 5

Insulation

SABIX®

Colour code

black cores with consecutive numbers acc. to EN 50334 + VDE 0293-334, green-yellow earth wire from 3 cores

Stranding

in layers

Sheath material

PUR, TMPU acc. to EN 50363-10-2 + VDE 0207-363-10-2

Sheath colour

black (RAL 9005)

Technical data

Nominal voltage

Uo/U 300/500 V

Testing voltage

core/core 2000 V

Min. bending radius

fixed laying: 4 x d

flexible application: 6 x d

Temperature range

fixed laying: -40/+90 °C

flexible application: -30/+90 °C

Halogen-free

acc. to IEC 60754-1 + VDE 0482-754-1

Fire performance

flame retardant and self-extinguishing acc. to IEC 60332-1-2 + VDE 0482-332-1-2

Oil resistance

very good - TMPU acc. to EN 50363-10-2 + VDE 0207-363-10-2

Chem. resistance

good against acids, alkalines, solvents, hydraulic liquids etc.

Flexibility

very good

Weather resistance

good

Absence of harmful substances

acc. to RoHS directive of the European Union

Nominal voltage

Uo/U 300/500 V

Testing voltage

core/core 2000 V

Min. bending radius

fixed laying: 4 x d

flexible application: 6 x d

Temperature range

fixed laying: -40/+90 °C

flexible application: -30/+90 °C

Halogen-free

acc. to IEC 60754-1 + VDE 0482-754-1

Fire performance

flame retardant and self-extinguishing acc. to IEC 60332-1-2 + VDE 0482-332-1-2

Oil resistance

very good - TMPU acc. to EN 50363-10-2 + VDE 0207-363-10-2

Chem. resistance

good against acids, alkalines, solvents, hydraulic liquids etc.

Flexibility

very good

Weather resistance

good

Dimensions

item no.

no. of cores x
cross section

largest single
wire-ø

outer-ø ± 5%

copper figure

cable weight ca.

527902102 x 1,00 mm²0,21 mm6,2 mm19,2 kg/km52 kg/km Send inquiry
527903103 x 1,00 mm²0,21 mm6,5 mm28,8 kg/km63 kg/km Send inquiry
527905105 x 1,00 mm²0,21 mm7,7 mm48 kg/km93 kg/km Send inquiry
527907107 x 1,00 mm²0,21 mm8,3 mm67,2 kg/km118 kg/km Send inquiry
5279121012 x 1,00 mm²0,21 mm11,1 mm115,2 kg/km196 kg/km Send inquiry
5279181018 x 1,00 mm²0,21 mm12,9 mm172,8 kg/km262 kg/km Send inquiry
5279241024 x 1,00 mm²0,21 mm15,4 mm230 kg/km369 kg/km Send inquiry
5279361036 x 1,00 mm²0,21 mm17,5 mm345,6 kg/km526 kg/km Send inquiry
5279501050 x 1,00 mm²0,21 mm20,8 mm480 kg/km722 kg/km Send inquiry
5279721072 x 1,00 mm²0,21 mm25,3 mm691,2 kg/km1045 kg/km Send inquiry
527902152 x 1,50 mm²0,26 mm6,8 mm28,8 kg/km66 kg/km Send inquiry
527903153 x 1,50 mm²0,26 mm7,2 mm43,2 kg/km81 kg/km Send inquiry
527905155 x 1,50 mm²0,26 mm8,5 mm72 kg/km121 kg/km Send inquiry
527907157 x 1,50 mm²0,26 mm9,2 mm100,8 kg/km150 kg/km Send inquiry
5279121512 x 1,50 mm²0,26 mm12,4 mm172,8 kg/km257 kg/km Send inquiry
5279181518 x 1,50 mm²0,26 mm14,4 mm259,2 kg/km369 kg/km Send inquiry
5279241524 x 1,50 mm²0,26 mm17,2 mm345,6 kg/km495 kg/km Send inquiry
527903253 x 2,50 mm²0,26 mm8,5 mm72 kg/km121 kg/km Send inquiry
527904254 x 2,50 mm²0,26 mm9,2 mm96 kg/km150 kg/km Send inquiry
527905405 x 4,00 mm²0,31 mm12,1 mm192 kg/km275 kg/km Send inquiry
527904604 x 6,00 mm²0,31 mm12,7 mm230,4 kg/km320 kg/km Send inquiry
item no.
no. of cores x
cross section
largest single
wire-ø
outer-ø ± 5%
copper figure
cable weight ca.
52790210
2 x 1,00 mm²
0,21 mm
6,2 mm
19,2 kg/km
52 kg/km
52790310
3 x 1,00 mm²
0,21 mm
6,5 mm
28,8 kg/km
63 kg/km
52790510
5 x 1,00 mm²
0,21 mm
7,7 mm
48 kg/km
93 kg/km
52790710
7 x 1,00 mm²
0,21 mm
8,3 mm
67,2 kg/km
118 kg/km
52791210
12 x 1,00 mm²
0,21 mm
11,1 mm
115,2 kg/km
196 kg/km
52791810
18 x 1,00 mm²
0,21 mm
12,9 mm
172,8 kg/km
262 kg/km
52792410
24 x 1,00 mm²
0,21 mm
15,4 mm
230 kg/km
369 kg/km
52793610
36 x 1,00 mm²
0,21 mm
17,5 mm
345,6 kg/km
526 kg/km
52795010
50 x 1,00 mm²
0,21 mm
20,8 mm
480 kg/km
722 kg/km
52797210
72 x 1,00 mm²
0,21 mm
25,3 mm
691,2 kg/km
1045 kg/km
52790215
2 x 1,50 mm²
0,26 mm
6,8 mm
28,8 kg/km
66 kg/km
52790315
3 x 1,50 mm²
0,26 mm
7,2 mm
43,2 kg/km
81 kg/km
52790515
5 x 1,50 mm²
0,26 mm
8,5 mm
72 kg/km
121 kg/km
52790715
7 x 1,50 mm²
0,26 mm
9,2 mm
100,8 kg/km
150 kg/km
52791215
12 x 1,50 mm²
0,26 mm
12,4 mm
172,8 kg/km
257 kg/km
52791815
18 x 1,50 mm²
0,26 mm
14,4 mm
259,2 kg/km
369 kg/km
52792415
24 x 1,50 mm²
0,26 mm
17,2 mm
345,6 kg/km
495 kg/km
52790325
3 x 2,50 mm²
0,26 mm
8,5 mm
72 kg/km
121 kg/km
52790425
4 x 2,50 mm²
0,26 mm
9,2 mm
96 kg/km
150 kg/km
52790540
5 x 4,00 mm²
0,31 mm
12,1 mm
192 kg/km
275 kg/km
52790460
4 x 6,00 mm²
0,31 mm
12,7 mm
230,4 kg/km
320 kg/km

Other dimensions and colours are possible on request.
