T413

Immersion protecting armatures for gauge slides Ø 3 mm

Immersion protecting armatures for gauge slides Ø 3 mm

Immersion protecting armatures for gauge slides Ø 3 mm

Construction

Protecting tube Form AS tapered measuring tip (quick response time)

■ 1.0305 Ø 15 x 2 mm

■ 1.4571 Ø 15 x 2 mm

■ 1.4762 Ø 15 x 2 mm

■ 1.4841 Ø 15 x 2 mm

Gauge slide

■ without gauge slide

■ with gauge slide - acc. to customer’s request

Fixing

■ without fixing     ■ with screw sockete G3/4 A

■ with stop flange     ■ with screw socket G1 A

■ with screw socket G1/2 A     ■ with screwed plug

Connection head

■ B (KE 021)     ■ DAN-WZ (KE 201)     ■ DAN-Z (KE 063)

■ DAN-WS (KE 203)     ■ DAN-S (KE 065)     ■ BNK (KK 028)

■ other connection head - acc. to customer’s request

Nominal length / inset length

■ 500/525 mm     ■ 1400/1425 mm    ■ 250/275 mm

■ 710/735 mm     ■ 2000/2025 mm    ■ 355/380 mm

■ 1000/1025 mm     ■ 180/205 mm

■ other length - acc. to customer’s request

Protecting tube Form AS tapered measuring tip (quick response time)

■ 1.0305 Ø 15 x 2 mm

■ 1.4571 Ø 15 x 2 mm

■ 1.4762 Ø 15 x 2 mm

■ 1.4841 Ø 15 x 2 mm

Gauge slide

■ without gauge slide

■ with gauge slide - acc. to customer’s request

Fixing

■ without fixing     ■ with screw sockete G3/4 A

■ with stop flange     ■ with screw socket G1 A

■ with screw socket G1/2 A     ■ with screwed plug

Connection head

■ B (KE 021)     ■ DAN-WZ (KE 201)     ■ DAN-Z (KE 063)

■ DAN-WS (KE 203)     ■ DAN-S (KE 065)     ■ BNK (KK 028)

■ other connection head - acc. to customer’s request

Nominal length / inset length

■ 500/525 mm     ■ 1400/1425 mm    ■ 250/275 mm

■ 710/735 mm     ■ 2000/2025 mm    ■ 355/380 mm

■ 1000/1025 mm     ■ 180/205 mm

■ other length - acc. to customer’s request
