T445

Screw-in protecting armatures for gauge slides Ø 6 mm

Screw-in protecting armatures for gauge slides Ø 6 mm

Screw-in protecting armatures for gauge slides Ø 6 mm

Construction

Protecting tube form BO without neck tube

- 1.4571 Ø 9 x 1 mm

- 1.4571 Ø 8 x 0,9 mm

- 1.4571 Ø 11 x 2 mm

- 1.4571 Ø 12 x 2,5 mm

Gauge slide

- without gauge slide

- with gauge slide - acc. to customer’s request

Screwed thread

- G 1/2 A

- G 3/4 A

- G 1 A

- M 20 x 1,5

- without

- other thread - acc. to customer’s request

Connection head

- B (KE 122)

- DAN-WZ (KE 202)

- DAN-Z (KE 064)

- DAN-WS (KE 204)

- DAN-S (KE 066)

- BNK (KK 029)

- without connection head

- other connection head - acc. to customer’s request

Immersion / inset length

- 100/145 mm

- 160/205 mm

- 250/295 mm

- 400/445 mm

- other length - acc. to customer’s request

Protecting tube form BO without neck tube

- 1.4571 Ø 9 x 1 mm

- 1.4571 Ø 8 x 0,9 mm

- 1.4571 Ø 11 x 2 mm

- 1.4571 Ø 12 x 2,5 mm

Gauge slide

- without gauge slide

- with gauge slide - acc. to customer’s request

Screwed thread

- G 1/2 A

- G 3/4 A

- G 1 A

- M 20 x 1,5

- without

- other thread - acc. to customer’s request

Connection head

- B (KE 122)

- DAN-WZ (KE 202)

- DAN-Z (KE 064)

- DAN-WS (KE 204)

- DAN-S (KE 066)

- BNK (KK 029)

- without connection head

- other connection head - acc. to customer’s request

Immersion / inset length

- 100/145 mm

- 160/205 mm

- 250/295 mm

- 400/445 mm

- other length - acc. to customer’s request
