T451

weld-in protecting armatures for gauge slides Ø 3 mm

Protecting tube form DS (quick response time)	- without - form D 4S - form D 5S
Protecting tube material	- 1.7335 - 1.7380 - 1.4571 - 1.5415 - 1.4961 - for design without protecting tube (welding sleeve)
Gauge slide	- without gauge slide - with gauge slide - acc. to customer’s request
Connection head	- B (KE 122) - DAN-WZ (KE 202) - DAN-Z (KE 064) - DAN-WS (KE 204) - DAN-S (KE 066) - BNK (KK 029) - without connection head - other connection head - acc. to customer’s request
Neck tube length	140 mm

Protecting tube form DS (quick response time)

- without

- form D 4S

- form D 5S

Protecting tube material

- 1.7335

- 1.7380

- 1.4571

- 1.5415

- 1.4961

- for design without protecting tube (welding sleeve)

Gauge slide

- without gauge slide

- with gauge slide - acc. to customer’s request

Connection head

- B (KE 122)

- DAN-WZ (KE 202)

- DAN-Z (KE 064)

- DAN-WS (KE 204)

- DAN-S (KE 066)

- BNK (KK 029)

- without connection head

- other connection head - acc. to customer’s request

Neck tube length

140 mm
