RTD 603

Mineral insulated resistance thermometer with Lemo connection end

Mineral insulated resistance thermometer with Lemo connection end

Mineral insulated resistance thermometer with Lemo connection end

Application

Mineral insulated resistance thermometer for measuring ranges from -50 to +600°C. We will gladly assist you in selecting the right temperature sensor for your specific application. You can also use the parameters below to put together your customized mineral insulated resistance thermometer.

Additional information

Sheath-Ø: 1,5 mm on request!

Construction

RTD

- 1 x Pt 100 class A

- 2 x Pt 100 class A

- 1 x Pt 100 class B

- 2 x Pt 100 class B

Circuit of inner wires

- 2-wire circuit

- 3-wire circuit

- 4-wire circuit

Sheath diameter

- 1,5 mm

- 3,0 mm

- 4,5 mm

- 6,0 mm

- other sheath diameter - acc. to customer’s request

Connection element

- socket size 0     - plug size 0

- socket size 1     - plug size 1

- socket size 2     - plug size 2

- other connection elements - acc. to customer’s request

Accessories (fix)

- without socket / plug housing

- with socket / plug housing

- special accessories - acc. to customer’s request

Measuring range

▪ -50 up to +400°C

▪ -50 up to +600°C

- other measuring range - acc. to customer’s request

Nominal length

According to customer requests. Please specify in mm.

RTD

- 1 x Pt 100 class A

- 2 x Pt 100 class A

- 1 x Pt 100 class B

- 2 x Pt 100 class B

Circuit of inner wires

- 2-wire circuit

- 3-wire circuit

- 4-wire circuit

Sheath diameter

- 1,5 mm

- 3,0 mm

- 4,5 mm

- 6,0 mm

- other sheath diameter - acc. to customer’s request

Connection element

- socket size 0     - plug size 0

- socket size 1     - plug size 1

- socket size 2     - plug size 2

- other connection elements - acc. to customer’s request

Accessories (fix)

- without socket / plug housing

- with socket / plug housing

- special accessories - acc. to customer’s request

Measuring range

▪ -50 up to +400°C

▪ -50 up to +600°C

- other measuring range - acc. to customer’s request

Nominal length

According to customer requests. Please specify in mm.
