Surface thermocouple 1000 °C
Surface thermocouple
Application
This temperature sensor made of fibre-glass insulated thermo wires, class 1, is resistant up to 1000°C. It can be used wherever simple fibre-glass elements are no longer sufficient, for example in battery issues tests (nail penetration) or in steel production on surfaces.
Construction
| Measuring tip | bare |
|---|---|
| Thermocouple | 1 x type K |
| Connection cable | Thermocouple cable, 2 x 0,50 mm², fibre-glass insulated, +1000°C |
| Connection cable length | - 0,50 m - 1,00 m - 1,50 m - 2,00 m - 3,00 m - 5,00 m - 10,0 m |
| Connection ends | - miniature thermoplug - miniature socket - standard plug - standard socket - free ends specify in mm - acc. to customer’s request - other connection ends |
| Possible on request | with batch certificate and identification |
bare
1 x type K
Thermocouple cable, 2 x 0,50 mm², fibre-glass insulated, +1000°C
- 0,50 m
- 1,00 m
- 1,50 m
- 2,00 m
- 3,00 m
- 5,00 m
- 10,0 m
- miniature thermoplug
- miniature socket
- standard plug
- standard socket
- free ends specify in mm - acc. to customer’s request
- other connection ends
with batch certificate and identification
Configuration examples
| item no. | Type | Measuring tip | Cable | Cable length | Connection ends | |
|---|---|---|---|---|---|---|
| T100-064-311 | K | bare | 1000°C fibre-glass | 3000 mm | miniature thermoplug | Send inquiry |
| T100-064-987 | K | bare | 1000°C fibre-glass | 5000 mm | miniature thermoplug | Send inquiry |
Other configurations are possible on request.
